How To Flash Reset Samsung I5700 Galaxy Spica Android 2.1


This is a complete guide to flash (upgrade) your Samsung I5700 Galaxy Spica to Android 2.1 (firmware EXXJCE (March 2010)). I have tested it on my own Spica with firmware version DXIL1 and two of my friends with firmware version DXJA1 and it really worked. You can use this guide to upgrade your Spica at your own risk and don’t blame me if you turn out your Spica into a bricked device :-) .
(This guide has been updated on 07 May 2010, find it at the bottom of this post)
MULTITOUCH now is enabled on Spica, check the guide on how to enable it here
What you need:
Alternative download links (Mydropbox, ads free, direct download) (Big thanx to Yousef):
Note for I5700 driver:
If windows doesn’t detect the phone in download mode, disconnect the phone & try to uninstall pc studio or kies then reboot. Reinstall pc studio or kies then connect the phone (you may also remove & insert the battery before connecting the phone).
Before start checklist:
  • Check your firmware using *#1234#
  • Backup your data (contacts, sms, etc)
  • Ensure that your phone battery power is sufficient
  • Release the SIM lock (check SIM lock status using *#7465625#)
  • Extract all required files into a folder (those files will be: I570EXXJCE.zip –> I570EXXJCE.tar; Odin_v4.03_spica_jc3_ops.rar –> Odin Multi Downloader v4.03.exe, spica_jc3.ops; jb4_bootloader.rar –> I570EXXJA1_CLI32638_Bootloader.tar, I570XXJB4_Phone.tar; I570EOLBJB3-CSC-CL167487-OLB.tar).
  • Shutdown or disable Antivirus and Samsung PC Studio if any.
How to flash:
Preparation
  1. Shutdown your phone and remove the SIM Card and SDCard.
  2. Press volume down + power button + camera to put the phone into download mode.
  3. Spica Download Mode
    Spica Download Mode
  4. Connect the phone to PC using USB cable. You can check the connection in Windows device manager, make sure that your phone is properly detected by Windows like picture below
  5. Windows Device Manager
    Windows Device Manager
  6. Run the Odin Multi Download v4.03.exe. If your phone is properly detected, the Com Port Mapping field should be in yellow background.
Flash I
  1. Select spica_jc3.ops into Select OPS field
  2. Select I570EXXJCE.tar into Selet Integrate Package – Choose One Package Option field
  3. Tick the One Package option
  4. Click Start to start flashing. The timer and progress bar above COM Port Mapping field should start . If the progress bar doesn’t start but the timer continue to run , close Odin and disconnect the phone from PC. Remove and insert the battery and start the phone in download mode again, then run Odin.
  5. Wait until PASS message appear in Message box and the progress bar box turns into blue.
  6. At this step, you may get the flashing seems to be failed, and you’ll see exclamation mark appears like image shown below. Don’t worry, this is not the end of your spica, close the Odin and disconnect the phone from PC.
  7. Remove and insert the battery, start the phone in download mode then run Odin again and follow the steps in Flash II.
  8. Click to enlarge
    Click to enlarge
Note: If you already get Eclair on this stage, skip the Flash II & III.
Flash II
  1. Keep spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clear the fields.
  3. In Select Images to download panel, Select I570EXXJA1_CLI32638_Bootloader.tar into BOOT field,I570XXJB4_Phone.tar into PHONE field, I570EOLBJB3-CSC-CL167487-OLB.tar into CSA field, and let the PDAfield empty.
  4. In Debug Option panel, tick Debug Only and PDA Format option. Don’t tick One Package option in Option Panel.
  5. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  6. Disconect the phone from PC, remove and insert the battery, start the phone in download mode again then continue to Flash III.
  7. Click to enlarge
    Click to enlarge
Flash III
  1. Keep spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clean the fields.
  3. In Select Images to download panel, Select I570EXXJCE.tar into PDA field.
  4. If you get an error dialog, rename the I570EXXJCE.tar into I570EXXJCE_PDA.tar and insert into PDA field again.
  5. Don’t select One Package option and Debug Option.
  6. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  7. The phone will restart and you will get the Eclair screen :-) .

  8. Click to enlarge
    Click to enlarge
Now you have the new Eclair in your Spica, but wait, firmare EXXJCE is french firmware, so you’ll get your Spica language in French, to change the language, enter paramètres menu at bottom corner then choose Paramètres de langue then Langue et règion and select your language.
Rooting Your New Eclair
In some cases, you may need your Spica to be rooted in order to install some applications like shootme, my favourite screen capture application. This is just optional, you don’t have to follow this step. I use LkMod v2.5.1 by Leshak that based on EXXJCE firmware to get my Spica rooted and get some additional features like live wallpaper and custom logo while booting my Spica.
LkMod 2.5.1 features:
  • New phone.apk (from xdadev)
  • Helixlauncher as default home (can be switched with default Pantheon)
  • Live wallpaper
  • Root (su)
  • Busybox
  • Remount
  • fdump for backup
  • Custom logo
What you need:
Create your custom logo (Optional)
Default logo comes with LkMod can be replaced with your own logo, you can replace the logo with your own using Photoshop or other image manipulating software.
How to change the logo:
  1. Install the GNU tar for windows, default location is on C:\Program Files\GnuWin32
  2. Extract LkMod-2_5_1-PDA.7z and you’ll get LkMod-2_5_1-PDA.tar
  3. Extract LkMod-2_5_1-PDA.tar and you’ll get four files: cache.rfs, datafs.rfs, logo.png and zImage.
  4. Create your own logo with 320×480 size and PNG file type. Warning: The size of logo file must be between 30-40 kb or the phone will never be able to boot!!.
  5. Save as logo.png and replace the default logo.png
  6. Package the four files using GNU tar command line program
  7. >C:\Program Files\GnuWin32\tar -cvf LkMod-2_5_1-PDA.tar cache.rfs datafs.rfs logo.png zImage
  8. You’ll get your own LkMod with your own custom logo (LkMod-2_5_1-PDA.tar)
How to flash
  1. Select spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clean the fields.
  3. In Select Images to download panel, Select LkMod-2_5_1-PDA.tar into PDA field.
  4. Don’t select One Package option and Debug Option.
  5. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  6. The phone will restart and you will get the rooted Eclair with helixlauncher default home.
Usefull information about Samsung Firmware
Europe
XA = Austria, France, Germany, Italy, Netherlands, Switzerland, UK
XB = Denmark, Norway, Sweden
XC = Portugal, Spain
XD = Croatia, Czech, Hungary, Slovakia
XE = Bulgaria, Estonia, Kazakhstan, Latvia, Lithuania, Russia, Ukraine
XF = Bulgaria, Croatia, Romania
XP = Dutch, French, Italian, Spanish, Dutch, Polski, Portuguese, Turkish
XW = UK, Italy, Germany, France, Australia, Netherlands, Belgium, Switzerland
XX = Austria, Belgium, France, Germany, Hungary, Italy, Spain, United Kingdom
Asia
DD = India
DX = Indonesia, Malaysia, Philippines, Singapore, Vietnam
ZC = China, Hong Kong
ZH = Hong Kong
Code = Year – Month
A = 2001 – January
B = 2002 – February
C = 2003 – March
D = 2004 – April
E = 2005 – May
F = 2006 – June
G = 2007 – July
H = 2008 – August
I = 2009 – September
J = 2010 – October
K = 2011 – Novermber
L = 2012 – December
Example,
My Spica has firmware version I5700DXIL1
DX = Indonesia, Malaysia, Philippines, Singapore, Vietnam
I = 2009
L = December
1 = Version
Update May 17, 2010
1. DXJC4 (Asia) Firmware
If you have flashed to JCE and want to reflash it to DXJC4, flash with DXJB3 first (complete package) using Sameer’s guide than flash to DXJC4 as one package.
2. EXXJD1+ Lk2.02 modd
If you are using JCE and want to upgrade to JD1, flash JD1 (complete package) using Sameer’s guide and then apply Leshak’s Lk2.02 mod.
3. F0r Indonesian users that use Europe firmware (jce,jcf,jd1), to overcome problem with 3 and im2 simcard:
- For rooted device without Lk2.02:
  • Download libsec-ril.so
  • Using ADB tool:
  • adb push libsec-ril.so /sdcard
  • adb shell
  • #mount -o remount,rw -t yaffs2 /dev/block/mtdblock3 /system
  • #cp /system/lib/libsec-ril.so /sdcard/libsec-ril.so.old (backup)
  • #cp /sdcard/libsec-ril.so /system/lib
  • #reboot
- For rooted device with Lk2.02 (has recovery tools)
  • Download im2-3-update.zip
  • Using ADB tool:
  • adb push im2-3-update.zip /sdcard
  • adb shell
  • #reboot recovery
  • From recovery menu, choose ‘Apply any zip from SD’
  • Select im2-3-update.zip
  • Press ‘Home’ for confirm
  • Reboot
4. Install Nexus One boot animation (win 7 style)
Nexus one boot animation file (bootanimation.zip) was taken from Leshak’s samdroid mod
- For rooted device without Lk2.02
  • Download bootanimation.zip
  • Using ADB tool:
  • adb push bootanimation.zip /sdcard
  • adb shell
  • #mount -o remount,rw -t yaffs2 /dev/block/mtdblock3 /system
  • #cp /system/media/bootani.qmg /sdcard (backup)
  • #cp /system/etc/poweron.snd /sdcard (backup)
  • #rm /sytsem/etc/poweron.snd
  • #cp /sdcard/bootanimation.zip /system/media
  • #reboot
- For rooted device with Lk2.02 (has recover tools)
  • Download nexusoneanim_update.zip
  • Using ADB tool:
  • adb push nexusoneanim_update.zip /sdcard
  • adb shell
  • #reboot recovery
  • From recovery menu, choose ‘Apply any zip from SD’
  • Select nexusoneanim_update.zip
  • Press ‘home’ for confirm
  • Reboot
5. Install Samdroid Mod 1.o.3
Samdroid 1.0.3 can be applied to any 2.1 firmwares + lk2.02 installed and has two partitions on sdcard (one should be ext2 partition).
  1. Install Lk2.02 (Ref: samdroid)
    • Download LK2-02-1_update.zip (rapid) | LK2-02-1_update.zip (mydropbox)
    • Copy it to root of sdcard (/sdcard)
    • Download i5700_LK2-02_PDA.tar (rapid) | i5700_LK2-02_PDA.tar (mydropbox)
    • Flash it using odin as PDA file
    • Spica will reboot and enter into recovery mode
    • Select ‘apply any zip from SD’
    • Select LK2-02-1_update.zip then pres’s Home’ to confirm
    • Wait until ‘Install from sd card complete’ appears then reboot
    • Check phone
  2. Apply app2sd (Ref: samdroid)
    • Turn off the phone
    • Press ‘Volume down + Call/Answer + Power’ key to enter into recovery mode OR
    • Using adb shell type ‘reboot recovery’
    • Select ‘Partition sd card’
    • Select the size of partition (256, 384 or 512) then press ‘Home’ to confirm
    • Wait until ‘Format SDCARD complete’ appears then reboot
    • Check phone
  3. Install samdroid (Ref: samdroid)
    • Press ‘Volume down + Call/Answer + Power’ key to enter into recovery mode OR
    • Using adb shell type ‘reboot recovery’
    • Select ‘wipe, choose what’ -> ‘data/cache’
    • Select ‘Apply any zip from SD’ and choose ‘SamdroidMod-1_0_3-update.zip’
    • Press ‘Home’ to confirm
    It may take a long time for first time booting (it is normal, you’ll see nexus one boot animation)
    Article Source
Read More

How to Enable Multitouch on Samsung Spica i5700


Samsung Spica users may have been happy since genius Gabriel-LG from samdroid.net made a patch to Spica’s kernel to enable multitouch support a week ago. The patch now is available in latest samdroid kitchen v2 (LK2.09.4) along with a patch for dark camera bug from antibyte. I’ve tested the latest samdroid kitchen with multitouch+camera fix patch, it works perfectly on Google Map, Gallery 3D and Browser. The camera dark problem also fixed.
There are several ways to install multitouch patch, but in this guide i’ll use patch that comes with latest samdroid kitchen v2 (kernel LK2.09.4). LK2.09.4 includes patches for multitouch from Gabriel-LG (v2b), camera bug fix from antibyte and new superuser 2.3.5.
How to install
Note: Use this guide at your own risk and always make a backup before applying new updates.
Without base package
Use this if you want to install kernel patch without samdroid v2 package. You must at least have kernel LK2.02 installed to install the patch via recovery.
  • Go to samdroid kitchen v2 page
  • On ‘Base Packages‘ options, choose ‘Light Package
  • On ‘Kernel’ options, choose ‘Kernel [LK2.09.4 (Multitouch from Gabriel-LG v2b + antibyte camera bugfix2 + Superuser 2.3.5)]
  • Scroll down the page (skip the other options) and click ‘Cook‘ button to download the zip file (SamdroidMod-(###)_update.zip). The samdroid update zip file size is about 3.8 mb .
  • Download multitouch fix zip file from here (Sdm_MultitouchFix.zip)
  • Copy the two update zip files into sdcard
  • Reboot into recovery
  • Select ’Apply any zip from SD
  • Select samdroid update zip file
  • Do the same for multitouch fix zip file
  • Reboot and check the multitouch support, you can download Multitouch Vis Test application from Market to test multitouch support.
With base package (Recommend, stable)
Use this if you want to install kernel patch with samdroid v2 package. You must at least have kernel LK2.02 installed to install the patch via recovery.
  • Go to samdroid kitchen v2 page
  • On ‘Base Packages‘ options, choose ‘SamdroidMod Version 1.3.1.deodexed [XXJH1] (Android 2.1)‘ and Light Package
  • On ‘Kernel’ options, choose ‘Kernel [LK2.09.4 (Multitouch from Gabriel-LG v2b + antibyte camera bugfix2 + Superuser 2.3.5)]
  • Choose your prefered packages on the other options. For ‘Home‘ options, LauncherPro is really recommended (smooth & fast launcher)
  • Click ‘Cook‘ button to download the zip file (SamdroidMod-(###)_update.zip). The file size is about 80-100 mb depends on your selected packages
  • Download multitouch fix zip file from here (Sdm_MultitouchFix.zip)
  • Copy the two update zip files into sdcard
  • Reboot into recovery
  • Select Wipe → Wipe data/cache
  • Select ’Apply any zip from SD
  • Select samdroid update zip file
  • Do the same for multitouch fix zip file
  • Reboot
  • First booting may take a long time, especially between logo and boot animation, just wait.
  • Check the multitouch support, you can download Multitouch Vis Test application from Market to test multitouch support.
Spica Multitouch Test
Spica Multitouch Test
Demo Video (from Gabriel)


Special thanks.
Read More

Flash Reset Samsung I5700 Galaxy Spica Android 2.1


This is a complete guide to flash (upgrade) your Samsung I5700 Galaxy Spica to Android 2.1 (firmware EXXJCE (March 2010)). I have tested it on my own Spica with firmware version DXIL1 and two of my friends with firmware version DXJA1 and it really worked. You can use this guide to upgrade your Spica at your own risk and don’t blame me if you turn out your Spica into a bricked device :-) .
(This guide has been updated on 07 May 2010, find it at the bottom of this post)
MULTITOUCH now is enabled on Spica, check the guide on how to enable it here
What you need:
Alternative download links (Mydropbox, ads free, direct download) (Big thanx to Yousef):
Note for I5700 driver:
If windows doesn’t detect the phone in download mode, disconnect the phone & try to uninstall pc studio or kies then reboot. Reinstall pc studio or kies then connect the phone (you may also remove & insert the battery before connecting the phone).
Before start checklist:
  • Check your firmware using *#1234#
  • Backup your data (contacts, sms, etc)
  • Ensure that your phone battery power is sufficient
  • Release the SIM lock (check SIM lock status using *#7465625#)
  • Extract all required files into a folder (those files will be: I570EXXJCE.zip –> I570EXXJCE.tar; Odin_v4.03_spica_jc3_ops.rar –> Odin Multi Downloader v4.03.exe, spica_jc3.ops; jb4_bootloader.rar –> I570EXXJA1_CLI32638_Bootloader.tar, I570XXJB4_Phone.tar; I570EOLBJB3-CSC-CL167487-OLB.tar).
  • Shutdown or disable Antivirus and Samsung PC Studio if any.
How to flash:
Preparation
  1. Shutdown your phone and remove the SIM Card and SDCard.
  2. Press volume down + power button + camera to put the phone into download mode.
  3. Spica Download Mode
    Spica Download Mode
  4. Connect the phone to PC using USB cable. You can check the connection in Windows device manager, make sure that your phone is properly detected by Windows like picture below
  5. Windows Device Manager
    Windows Device Manager
  6. Run the Odin Multi Download v4.03.exe. If your phone is properly detected, the Com Port Mapping field should be in yellow background.
Flash I
  1. Select spica_jc3.ops into Select OPS field
  2. Select I570EXXJCE.tar into Selet Integrate Package – Choose One Package Option field
  3. Tick the One Package option
  4. Click Start to start flashing. The timer and progress bar above COM Port Mapping field should start . If the progress bar doesn’t start but the timer continue to run , close Odin and disconnect the phone from PC. Remove and insert the battery and start the phone in download mode again, then run Odin.
  5. Wait until PASS message appear in Message box and the progress bar box turns into blue.
  6. At this step, you may get the flashing seems to be failed, and you’ll see exclamation mark appears like image shown below. Don’t worry, this is not the end of your spica, close the Odin and disconnect the phone from PC.
  7. Remove and insert the battery, start the phone in download mode then run Odin again and follow the steps in Flash II.
  8. Click to enlarge
    Click to enlarge
Note: If you already get Eclair on this stage, skip the Flash II & III.
Flash II
  1. Keep spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clear the fields.
  3. In Select Images to download panel, Select I570EXXJA1_CLI32638_Bootloader.tar into BOOT field,I570XXJB4_Phone.tar into PHONE field, I570EOLBJB3-CSC-CL167487-OLB.tar into CSA field, and let the PDAfield empty.
  4. In Debug Option panel, tick Debug Only and PDA Format option. Don’t tick One Package option in Option Panel.
  5. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  6. Disconect the phone from PC, remove and insert the battery, start the phone in download mode again then continue to Flash III.
  7. Click to enlarge
    Click to enlarge
Flash III
  1. Keep spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clean the fields.
  3. In Select Images to download panel, Select I570EXXJCE.tar into PDA field.
  4. If you get an error dialog, rename the I570EXXJCE.tar into I570EXXJCE_PDA.tar and insert into PDA field again.
  5. Don’t select One Package option and Debug Option.
  6. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  7. The phone will restart and you will get the Eclair screen :-) .

  8. Click to enlarge
    Click to enlarge
Now you have the new Eclair in your Spica, but wait, firmare EXXJCE is french firmware, so you’ll get your Spica language in French, to change the language, enter paramètres menu at bottom corner then choose Paramètres de langue then Langue et règion and select your language.
Rooting Your New Eclair
In some cases, you may need your Spica to be rooted in order to install some applications like shootme, my favourite screen capture application. This is just optional, you don’t have to follow this step. I use LkMod v2.5.1 by Leshak that based on EXXJCE firmware to get my Spica rooted and get some additional features like live wallpaper and custom logo while booting my Spica.
LkMod 2.5.1 features:
  • New phone.apk (from xdadev)
  • Helixlauncher as default home (can be switched with default Pantheon)
  • Live wallpaper
  • Root (su)
  • Busybox
  • Remount
  • fdump for backup
  • Custom logo
What you need:
Create your custom logo (Optional)
Default logo comes with LkMod can be replaced with your own logo, you can replace the logo with your own using Photoshop or other image manipulating software.
How to change the logo:
  1. Install the GNU tar for windows, default location is on C:\Program Files\GnuWin32
  2. Extract LkMod-2_5_1-PDA.7z and you’ll get LkMod-2_5_1-PDA.tar
  3. Extract LkMod-2_5_1-PDA.tar and you’ll get four files: cache.rfs, datafs.rfs, logo.png and zImage.
  4. Create your own logo with 320×480 size and PNG file type. Warning: The size of logo file must be between 30-40 kb or the phone will never be able to boot!!.
  5. Save as logo.png and replace the default logo.png
  6. Package the four files using GNU tar command line program
  7. >C:\Program Files\GnuWin32\tar -cvf LkMod-2_5_1-PDA.tar cache.rfs datafs.rfs logo.png zImage
  8. You’ll get your own LkMod with your own custom logo (LkMod-2_5_1-PDA.tar)
How to flash
  1. Select spica_jc3.ops in Select OPS field.
  2. Click Reset Files to clean the fields.
  3. In Select Images to download panel, Select LkMod-2_5_1-PDA.tar into PDA field.
  4. Don’t select One Package option and Debug Option.
  5. Click Start and watch the progress bar and timer, wait untill PASS message appear on Message box.
  6. The phone will restart and you will get the rooted Eclair with helixlauncher default home.
Usefull information about Samsung Firmware
Europe
XA = Austria, France, Germany, Italy, Netherlands, Switzerland, UK
XB = Denmark, Norway, Sweden
XC = Portugal, Spain
XD = Croatia, Czech, Hungary, Slovakia
XE = Bulgaria, Estonia, Kazakhstan, Latvia, Lithuania, Russia, Ukraine
XF = Bulgaria, Croatia, Romania
XP = Dutch, French, Italian, Spanish, Dutch, Polski, Portuguese, Turkish
XW = UK, Italy, Germany, France, Australia, Netherlands, Belgium, Switzerland
XX = Austria, Belgium, France, Germany, Hungary, Italy, Spain, United Kingdom
Asia
DD = India
DX = Indonesia, Malaysia, Philippines, Singapore, Vietnam
ZC = China, Hong Kong
ZH = Hong Kong
Code = Year – Month
A = 2001 – January
B = 2002 – February
C = 2003 – March
D = 2004 – April
E = 2005 – May
F = 2006 – June
G = 2007 – July
H = 2008 – August
I = 2009 – September
J = 2010 – October
K = 2011 – Novermber
L = 2012 – December
Example,
My Spica has firmware version I5700DXIL1
DX = Indonesia, Malaysia, Philippines, Singapore, Vietnam
I = 2009
L = December
1 = Version
Update May 17, 2010
1. DXJC4 (Asia) Firmware
If you have flashed to JCE and want to reflash it to DXJC4, flash with DXJB3 first (complete package) using Sameer’s guide than flash to DXJC4 as one package.
2. EXXJD1+ Lk2.02 modd
If you are using JCE and want to upgrade to JD1, flash JD1 (complete package) using Sameer’s guide and then apply Leshak’s Lk2.02 mod.
3. F0r Indonesian users that use Europe firmware (jce,jcf,jd1), to overcome problem with 3 and im2 simcard:
- For rooted device without Lk2.02:
  • Download libsec-ril.so
  • Using ADB tool:
  • adb push libsec-ril.so /sdcard
  • adb shell
  • #mount -o remount,rw -t yaffs2 /dev/block/mtdblock3 /system
  • #cp /system/lib/libsec-ril.so /sdcard/libsec-ril.so.old (backup)
  • #cp /sdcard/libsec-ril.so /system/lib
  • #reboot
- For rooted device with Lk2.02 (has recovery tools)
  • Download im2-3-update.zip
  • Using ADB tool:
  • adb push im2-3-update.zip /sdcard
  • adb shell
  • #reboot recovery
  • From recovery menu, choose ‘Apply any zip from SD’
  • Select im2-3-update.zip
  • Press ‘Home’ for confirm
  • Reboot
4. Install Nexus One boot animation (win 7 style)
Nexus one boot animation file (bootanimation.zip) was taken from Leshak’s samdroid mod
- For rooted device without Lk2.02
  • Download bootanimation.zip
  • Using ADB tool:
  • adb push bootanimation.zip /sdcard
  • adb shell
  • #mount -o remount,rw -t yaffs2 /dev/block/mtdblock3 /system
  • #cp /system/media/bootani.qmg /sdcard (backup)
  • #cp /system/etc/poweron.snd /sdcard (backup)
  • #rm /sytsem/etc/poweron.snd
  • #cp /sdcard/bootanimation.zip /system/media
  • #reboot
- For rooted device with Lk2.02 (has recover tools)
  • Download nexusoneanim_update.zip
  • Using ADB tool:
  • adb push nexusoneanim_update.zip /sdcard
  • adb shell
  • #reboot recovery
  • From recovery menu, choose ‘Apply any zip from SD’
  • Select nexusoneanim_update.zip
  • Press ‘home’ for confirm
  • Reboot
5. Install Samdroid Mod 1.o.3
Samdroid 1.0.3 can be applied to any 2.1 firmwares + lk2.02 installed and has two partitions on sdcard (one should be ext2 partition).
  1. Install Lk2.02 (Ref: samdroid)
    • Download LK2-02-1_update.zip (rapid) | LK2-02-1_update.zip (mydropbox)
    • Copy it to root of sdcard (/sdcard)
    • Download i5700_LK2-02_PDA.tar (rapid) | i5700_LK2-02_PDA.tar (mydropbox)
    • Flash it using odin as PDA file
    • Spica will reboot and enter into recovery mode
    • Select ‘apply any zip from SD’
    • Select LK2-02-1_update.zip then pres’s Home’ to confirm
    • Wait until ‘Install from sd card complete’ appears then reboot
    • Check phone
  2. Apply app2sd (Ref: samdroid)
    • Turn off the phone
    • Press ‘Volume down + Call/Answer + Power’ key to enter into recovery mode OR
    • Using adb shell type ‘reboot recovery’
    • Select ‘Partition sd card’
    • Select the size of partition (256, 384 or 512) then press ‘Home’ to confirm
    • Wait until ‘Format SDCARD complete’ appears then reboot
    • Check phone
  3. Install samdroid (Ref: samdroid)
    • Press ‘Volume down + Call/Answer + Power’ key to enter into recovery mode OR
    • Using adb shell type ‘reboot recovery’
    • Select ‘wipe, choose what’ -> ‘data/cache’
    • Select ‘Apply any zip from SD’ and choose ‘SamdroidMod-1_0_3-update.zip’
    • Press ‘Home’ to confirm
    It may take a long time for first time booting (it is normal, you’ll see nexus one boot animation)
    Article Source
Read More

Disclaimer

The materials on 4etc.blogspot.com’s web site are provided "as is" 4etc.blogspot.com makes no warranties, expressed or implied, and hereby disclaims and negates all other warranties, including without limitation, implied warranties or conditions of merchantability, fitness for a particular purpose, or non-infringement of intellectual property or other violation of rights. Further, 4etc.blogspot.com does not warrant or make any representations concerning the accuracy, likely results, or reliability of the use of the materials on its Internet web site or otherwise relating to such materials or on any sites linked to this site.

About Us

Blog Mania is about all of stuff. You can find each and everything here. Site is under-construction yet. Soon you will get all helpful stuff here. Please subscribe us to follow and share informative data to others too by use sharing button given at below of each post. We hope we will figure out you on best direction.

© 4etc | Blogger | Blogspot | Makhdoom Kadri | Makhdoom | Makhdoom Qadri , AllRightsReserved.

Designed by ScreenWritersArena
